Australia's Marine Satellite TV Antenna

		FEATURES
	Silent Operation			Made on The Gold Coast Australia
	Australian Specification LNB			Fully Automatic Operation
	AutoSkew of LNB			12/24vdc - 110/240vac Operation
	Internal 72 Channel GPS			Australian Owned and Made
	Quad Output for Foxtel and VAST			Automotive Plastic Dome
	IQ4 and 4K Compatable			Dome Painted in Black or White
	Bluetooth with Android App			316 Stainless Steel Hardware
	Fully Powder Coated Internally			Super Low Power Operation
	Oversized Quite Drive Motors			Remote Panel Mount Control Box

MODEL	O45HD	O60HD
Boat Size	34' to >60'	50' or Bigger
Antenna Type	Parabola	Parabola
Dish Diameter	450mm	600mm
Dome Size H x W	520mm x 550mm	690mm x 700mm
ActiveTrack	Yes - Silent Operation	Yes - Silent Operation
Minimum EIRP	48-49dBW	46-47dBW
Stabilisation	3 Axis	3 Axis
Elevation	0° to 90°	0° to 90°
Azimuth Range	680°	680°
GPS	Inbuilt 72 channel (GPS & GLONASS)	Inbuilt 72 channel (GPS & GLONASS)
AutoSkew LNB	YES	YES
Power Usage - Watts	15 watts	20 watts
Multiple Outputs	YES (4)	YES (4)
HD-IQ-4K Compatible	YES	YES
VAST/FTA Compatible	YES	YES
LNB Aus Spec	Quad Broadband (10.7 LO)	Quad Broadband (10.7 LO)
Internal Powder Coating	YES	YES
12 or 24vdc Operation	YES	YES
110 or 240vac Operation	YES	YES
Panel Mounted ACU	YES	YES
Mounting Hardware	YES - 316 Stainless	YES - 316 Stainless
Plug and Play	YES	YES
World Satellite Library	YES	YES
Bluetooth Enabled	YES	YES
Android Control APP	YES (Available)	YES (Available)
Dome And Base Painted	YES (White or Black Standard)	YES (White or Black Standard)
Antenna Mounts Available	75mm or 150mm	75mm or 150mm
